Manufacturer - Lnm
Part Number - EC914SM
Product Dimensions - 46.99 x 40.64 x 40.64 cm; 18.6 kg
Item model number - EC914S
Power Source - Corded Electric
Voltage - 120 Volts
Maximum power - 1.3 Horsepower
Item Package Quantity - 1
Sound level - 73 Decibels
Special Features - Portable
Included Components - EC914S compressor
Batteries included? - No
Batteries Required? - No
Item Weight - 18.6 kg
ABOUT THE PUMP
Heavy-Duty
Single Stage
Cast-Iron Twin Cylinders
Ball Bearings
Splash Lubricated
Hardened Steel Valve Plates with Swedish Lamellar Reed Valves
Aluminum Alloy Connecting Rods with Automotive-Style Inserts
Multi-Finned 11" Flywheel
Oil Sight Gauge
ABOUT THE MOTOR
1.5 HP
1755 RPM
Open Drip Proof
115/230 Volt – 60 Hz
Ball Bearings
Overload Protection w/Manual Reset
STANDARD EQUIPMENT
Pressure Gauge 0-200 in 5 lb. Graduations
Square D Pressure Switch with Unloader
Accessory Support Clip
Intake Filter with Silencer and Replaceable Element
Air-Cooled Aftercooler
Totally Enclosed Steel Belt Guard
Safety Relief Valve
